SMD aluminum electrolytic capacitor must meet below requirements for LED lighting source.

-Enduring high temperature, Enduring high ripple current

-Long lifetime, Cover full voltage range

-Suitable sizes, Low price

VK7 (Miniature type)

Characteristics: 105℃ 4000Hrs～6000Hrs, 7.7mm height, super small size.

Rated Voltage(V.DC):6.3V～400V (-40℃～+105℃);

Rated Capacitance(μf):1-680μF

Size: ≤Φ10×7.7, ≥Φ5×7.7

Working temperature:≤80℃,Ensure 30000Hrs lifetime.

Application: Specially designed for Mini size integrated LED power supply, available for high density and full automatic surface mounting and high temperature reflow soldering products.

VKO (Economic type)

Characteristics: 105℃ 6000Hrs ～8000Hrs,

Mini size, enduring high frequency and large ripple current.

Rated Voltage(V.DC):10V～100V (-55℃～+105℃);  160V～500V (-40℃～+105℃)

Rated Capacitance(μf):0.47-10000μF

Size: ≤Φ20×21.5, ≥Φ5×10

Working temperature:≤80℃,Ensure 30000Hrs lifetime.

Application: Specially designed for high advance LED power supply, available for high density and full automatic surface mounting and high temperature reflow soldering products.

VKM (Standard type)

Characteristics: 105℃ 7000Hrs ～10000Hrs,

Long life, Mini size, enduring high frequency and large ripple current.

Rated Voltage(V.DC):10V～100V (-55℃～+105℃); 160V～500V (-40℃～+105℃)

Rated Capacitance(μf):0.47-10000μF

Size: ≤Φ20×21.5, ≥Φ5×10

Working temperature:≤80℃,Ensure 50000Hrs lifetime.

Application: Specially designed for Long life LED power supply, available for high density and full automatic surface mounting and high temperature reflow soldering products.

VKG (Long lifetime type)

Characteristics: 105℃ 8000Hrs ～12000Hrs,

Long life, enduring high frequency and large ripple current.

Rated Voltage(V.DC):10V～100V (-55℃～+105℃); 160V～500V (-40℃～+105℃)

Rated Capacitance(μf):0.47-4700μF

Size: ≤Φ20×21.5, ≥Φ5×10

Working temperature:≤80℃,Ensure 80000Hrs lifetime.

Application: Specially designed for much Longer life LED power supply, available for high density and full automatic surface mounting and high temperature reflow soldering products.

VKL (High temperature type)

Characteristics: 125℃ 2000Hrs～5000Hrs,

High temperature, enduring high frequency and large ripple current.

Rated Voltage(V.DC):10V～100V (-40℃～+125℃); 160V～450V (-25℃～+125℃)

Rated Capacitance(μf):0.47-4700μF

Size: ≤Φ20×21.5,≥Φ5×10

Working temperature:≥100℃

Application: Specially designed for various high advanced LED power supply, available for high density and full automatic surface mounting and high temperature reflow soldering products.
